The heart of the IT - HSPD 100 is its submersible pump, which is designed for optimal performance in underwater environments. This pump is constructed with materials that are highly resistant to corrosion, such as stainless steel and specialized alloys. The submersible design allows the pump to be placed directly in the water, reducing the need for long suction pipes that can cause energy losses. By being submerged, the pump can create a more efficient suction force, drawing in water and sediment with greater ease
The IT - HSPD 100 is powered by a hydraulic system, which provides the necessary force to drive the submersible pump. The hydraulic power pack, often equipped with a diesel engine, generates high - pressure hydraulic fluid. This fluid is then transmitted through a series of hoses and valves to the hydraulic motor connected to the pump. The hydraulic system offers precise control over the pump's speed and power output. Operators can adjust the flow and pressure of the hydraulic fluid, enabling the dredger to adapt to different types of sediment and dredging conditions. For example, in areas with thick, compacted sediment, the operator can increase the hydraulic pressure to ensure the pump can effectively break up and suction the material.
When the IT - HSPD 100 is deployed, the submersible pump is lowered to the desired depth in the water body. The hydraulic motor, powered by the hydraulic system, starts to rotate the pump's impeller. The impeller's rotation creates a centrifugal force that draws in water and sediment from the surrounding area. The mixture, known as slurry, is then forced through the pump and into a discharge pipeline. The discharge pipeline transports the slurry to a designated disposal area, such as a spoil ground or a processing facility. The entire process is coordinated by the operator, who monitors and adjusts the hydraulic system parameters to ensure smooth and efficient operation.
One of the primary applications of the ESPD 100 is in river and canal dredging. Over time, rivers and canals accumulate sediment, debris, and other materials, which can reduce their depth and capacity. This can lead to problems such as flooding, reduced water flow, and navigation difficulties. The ESPD 100 can be used to remove these accumulated materials, restoring the waterways to their optimal condition. It can clear the channels, deepen the water depth, and improve the overall flow of water, ensuring safe and efficient navigation for boats and ships.
Harbors and ports are vital for international trade and transportation. To ensure the smooth operation of these facilities, regular maintenance is required. The ESPD 100 plays a crucial role in harbor and port dredging. It can remove the sediment that accumulates in the berths, channels, and basins, allowing larger vessels to dock and maneuver safely. By maintaining the required depth of the water in these areas, the dredger helps to increase the capacity of the harbor or port, facilitating the movement of goods and people.
Land reclamation projects involve creating new land from underwater areas. The ESPD 100 is an essential tool in such projects. It can dredge large quantities of sand, gravel, and other materials from the seabed or riverbed and transport them to the reclamation site. These materials are then used to build up the land, creating new areas for various purposes, such as residential development, industrial parks, and recreational facilities. The high - capacity and efficient operation of the ESPD 100 make it suitable for large - scale land reclamation projects.
In some mining operations, especially those involving underwater deposits, the ESPD 100 can be used to extract valuable minerals. It can dredge the ore - bearing materials from the bottom of lakes, seas, or other water bodies and transport them to the surface for further processing. The ability of the dredger to handle different types of materials and operate at various depths makes it a valuable asset in the mining industry, enabling the extraction of minerals that would otherwise be difficult to access.
The ESPD 100 also has applications in environmental restoration projects. For example, in lakes and ponds that have become polluted or filled with excessive sediment, the dredger can be used to remove the contaminated materials. This helps to improve water quality, restore the natural ecosystem, and enhance the aesthetic appeal of the water body. By removing the sediment and pollutants, the dredger can create a healthier environment for aquatic life and promote the overall ecological balance.
The hydraulic submersible dredge pump suction dredger ESPD 100 is a highly sophisticated and versatile piece of equipment. Its unique specifications, features of the hydraulic power pack and submersible pump, and wide range of applications make it an indispensable tool in various industries related to underwater excavation and material handling. Whether it is for maintaining waterways, developing new land, extracting minerals, or restoring the environment, the ESPD 100 offers reliable and efficient performance, contributing significantly to the success of numerous projects around the world.
The HSPD 100 is designed with a compact yet robust structure. Its overall dimensions are carefully optimized to ensure ease of transportation and maneuverability in various water bodies.
| Parameter | Value/Description |
| Model | IT-HSPD 100 |
| Power Source | Hydraulic |
| Power | 30-90 kW |
| Max Flow Rate | 80-120 m³/h |
| Max Head | 15-50 meters |
| Max Submersible Depth | 15 meters |
| Solid Handling | Up to 45% solids by weight; Max particle size: 30-60 mm |
| Pump Type | Centrifugal slurry pump with high-chrome alloy impeller and casing |
| Discharge Diameter | 100 mm (4") |
