Vietnam Suction Dredger

Dredging Background of Vietnam

By doing research and analysis from Blackridge, Vietnam is a southeast Asian country with over 97 million people. The dredging industry is an important infrastructure to maintain waterways and ports, and the country of Vietnam has a tropical climate with high levels of rainfall. The government controlled dredging companies and private sectors are relatively well developing the dredging activities in Vietnam. The projects, like including the Haiphong Port Dredging Project and the Saigon River Dredging Project, are government investment in recent years on majoy transportation hubs in Vietnam country, which aim to improve the Haiphong Port and the Saigon River.

In addition to those government invested dredging projects, the private dredging companies are also playing an important role in Vietnam dredging projects, who offer a range of design, construction, and maintenance services on dredging projects.

The research also shows that, with the stable increasing demand of improved infrastructure, the government and private dredging company are going to continue on the investment on the dredging industry in the coming years. The growing dredging activities in Vietnam will not only help the government and private dredging companies, but also benefit the business activities on transportation and trade, with the help on maintain waterways and ports.

Cutter Suction Dredger

In general, cutter suction dredger is a stationary dredging equipment with cutter device on the top, which can dig into the soil and driven by electric or hydraulic system, excavate the sand, a powered sand dredge pump can suck the soil and flow out through a pipeline.

The cutter suction dredger is capable to all kind of materials, including sand, rock, gravel, mud, ash etc, during the cutter suction dredger operation, it moves around a spud pole by pulling and slacking on the two fore sideline wires, and they are driven by swing winches.

Working Method - Cutter Suction Dredger

The rotating cutter head is attached on the ladder connected with the cutter suction dredger, and the cutter head is powered by hydraulic system or electric motor generated from the diesel engine.

The cutter head lows down by slacking on the ladder winch wires, and it excavates the soil during the dredging process, cutter head is moved by swing (side) winches, form port side to starboard and vise versa.

The swing winches (side winches) are playing an important role on cutter head movement, therefore, the selection on winches not only depends on the type of soil, but also the rotation direction of the cutter head, over cutting rotation in the direction of the swing movement.

Cutter suction dredgers can dredger all kind of soil materials, therefore, cutter suction dredger is the most common selection in dredging equipment, they are highly applied for dredging harbors, channels, reclamation areas and so on. The cutter suction dredger is very useful when the accuracy of the works is important. With long distance of piping, booster pump stations are required, and when suction depth is deep, the ladder submerged dredging pumps are needed.

Vietnam Cutter Suction Dredger - IHC

Xuan Thien Group, a construction and infrastructure development company in Vietnam, who was founded in 2000, formerly known as Xuan Thien Ninh Binh Company Limited, underwent restructuring in January 2022 to become a Group. Over the past 20 years of construction and development, Xuan Thien Group has made remarkable strides, becoming a leading, diversified Group in Vietnam with stable and sustainable growth.

Vietnam Xuan Thien Group has recently embarked on a significant dredging project in Ninh Binh, to improve waterways and support sustainable urban development, the company has bought IHC Beaver® dredgers 45 and 65, cutter suction dredger 450 and cutter suction dredger 650, in order to enhance navigation and prevent flooding in the region.

During the selection on cutter suction dredger 450 and CSD650, IHC consultant facilitated the size and type of dredger, in order to introduce the most efficiency dredging requirement in various dredging tasks on soil type and dredging material. Reported from “dredging today”.

The dredging services from IHC on cutter suction dredger CSD450 and CSD650 is not only on the suction dredging equipment selection, but also the design on dredging project plan, introducing the dredging activities, and specifically on the dredging equipment operation.

Vietnam Cutter Suction Dredger - IHC

News on 20th July 2023, Vietnam company: DACINCO investment construction company, who is specialized in construction of road, house, bridge and water system in Vietnam, had a contract with Royal IHC supplying the third Beaver® cutter suction dredger 650 DDSP, after the second cutter suction dredger Beaver® 65, the DACINCO 01 was delivered in June.

Announced from Alexander van den Berg, Director Dredging Standard Modular Vessels at Royal IHC: "The order for this third Beaver® demonstrates DACINCO's satisfaction and we are pleased to be able to support them in the further development of their dredging department with our vessels, equipment and services. We are very proud that the collaboration between DACINCO and IHC Dredging has developed into a solid relationship in a relatively short period of time.” Referenced from Royal IHC news.

The Beaver® 65 DDSP a reliable and fuel efficient cutter suction dredger, which has low maintenance costs and it is extremely productive at all the dredging depths for different output materials. The cutter suction dredger has main features of:
• low cost per cubic metre
• a diesel directly driven submerged pump (DDSP) that makes it possible to dredge at high-mixture densities
• the Curve® impeller that combines high efficiency with excellent suction performance and low-energy consumption
• first class ergonomics and diagnostics
• wear-resistant parts for the dredge pump
• class certification (BV Coastal area)
• integrated spud carriage installation.

Dimensions of the cutter suction dredger 65 DDSP
Length overall (ladder raised), approx. 58.0m
Length over pontoons 43.50m
Breadth 12.44m
Depth 2.97m
Side pontoons 43.50 x 4.67 x 2.97m
Average draught (50% consumables) 1.9m (approx.)
Maximum design draught 2.02m
Maximum standard dredging depth 18.0m
Suction/discharge pipe diameter 650mm
Total installed power 2,819kW

Swing width with 35° swing each side
At maximum dredging depth 48.5m
At minimum dredging depth 59.5m
Dredge pump Type IHC HR/MD 121-26-60, with Curve® impeller inside
Engine type Caterpillar 3516C SCAC Continuous engine power 1,825kW @1,600rpm
Specific fuel consumption 206.9g/kWhr

IADC – PIANC dredging conference in Vietnam

News from Dredging Today, in order to support dredging industry in Vietnam, IADC and PIANC have announced that there will be one-day dredging conference on 18th of October 2024, and the conference is going to take place in Ho Chi Minh City, Vietnam.

The conference is going to dedicate the advancing dredging knowledge and related topics, with the professionals and dredging company will attend to the conference, who are aiming to deliver the best advanced technology into the dredging projects, in order to maximize the benefits to Vietnam society, nature and economy.

More than that, the dredging conference ‘Integrating Dredging in Sustainable Development’ will bring essential knowledge for planners, designers, decision makers, regulators, contractors, project owners and environmental advocates.

Damen opens new service hub in Vietnam

Damen, Dutch dredging company, in order to provide best services in dredging industry in Vietnam market, it has opened its twelfth service hub, located in South-East Asia at Damen Song Cam shipyard in Haiphong, Vietnam. This service hub network can enable Damen dredging company to provide a dedicated resources, including faster delivery, comprehensive maintenance, and other life cycle support services.
Damen Services South-East Asia will start out supporting Damen’s Warranty and Asset Management Design department in Gorinchem, delivering warranty support activities for vessels operating in the region. It will also assist with optimising onboard systems on all vessels delivered by Damen Song Cam Shipyard. Thereafter it will expand its capabilities to enable it to offer a full range of business services.

Benefits of the new hub include:
Improved client support in the South-East Asia area. Being physically closer to its clients and with minimal time zone differences enable Damen to deliver a stronger client focus and faster response times.
With its location at Damen Song Cam Shipyard, hub engineers can directly access the knowledge of their colleagues who built the vessels.
Backed by Damen Services head office in Gorinchem, the Netherlands, the hub will be offering lifecycle support for vessels across the region.

ITECH CUTTER SUCTION DREDGER

Product Parameter

Model	Dredging Capacity	Dredging Depth	Suction/Discharge Pipe Dia.	Engine(s) Power
CSD-200	500 m3 /hr	1-5 m	200/200 mm	160-300 kw
CSD-250	800 m3 /hr	1-8 m	250/250 mm	200-400 kw
CSD-300	1200 m3 /hr	1-12 m	300/300 mm	400-600 kw
CSD-400	2200 m3 /hr	1.5-14 m	400/400 mm	700-1200 kw
CSD-500	3500 m3 /hr	1.5-15 m	600/500 mm	1100-1600 kw
CSD-650	5000 m3 /hr	1.5-18 m	650/650 mm	2200-2500 kw
CSD-700	7000 m3 /hr	1.5-20m	750/700 mm	2800-3500 kw

Vietnam Jet Suction Dredger

Itech dredge has successfully supplied Jet suction dredger JSD 300 into Vietnam market, the jet suction dredger is designed with high efficiency, effective fuel consumption, viable suction depth etc. The jet suction dredger is using pressure water jet pump powered by diesel engine to erode the sand bed and mixture the soil with water, a powered sand dredge pump is designed for sand dredging and piping.

Product Parameter

No.	Item		JSD200	JSD250	JSD300	JSD350	JSD400
1	Dredge performance	Sand capacity (cbm/hr)	80-110	130-260	300-360	360-390	440-520
2		Max. Discharge distance (m)	200-600	200-1000	200-1500	200-1800	200-2000
3		Max. gravel diameter passing through (mm)	50-60	60-70	60-70	60-70	60-80
4		Max. dreding depth (m)	15	15	15	20	20
5	Dredge body	Size (LxWxH) (mm)	8x1x1.5, 2 PCS 6×2.25×1.5, 1PCS	8x1x1.5, 2 PCS 6×2.25×1.5, 1PCS	11.8×1.1×1.5, 2 PCS 8×2.25×1.8, 1PCS	18×1.1×1.5, 2 PCS	18×1.1×1.5 2 PCS
6	Sand suction systerm	Pump size (inch)	8/6	10/8	12/10	14/12	16/14
7		Pump flow (cbm/hr)	410-540	620-1450	1650-1800	1800-1950	2200-2600
8		Pump head (m)	28-48	21-35	24-35	24-35	30-50
9		Pump speed (rpm)	730-980	730	730	730	550-700
10		Main engine power (KW)	132-156	180-250	250-300	300-410	410-460
11		Gearbox	Yes	Yes	Yes	Yes	Yes
12		Connect metal base	Include	Include	Include	Include	Include
13		High pressure water pump	jetting sand up	jetting sand up	jetting sand up	jetting sand up	jetting sand up
14	Electric power system	Generator	electric power	electric power	electric power	electric power	electric power
15	Control system	Control room	Yes	Yes	Yes	Yes	Yes
16	Control system	Control board	Yes	Yes	Yes	Yes	Yes
17	Lifting appliance	Electric winch	Yes	Yes	Yes	Yes	Yes
18	Propeller equipment	Propeller with engine	movement	movement	movement	movement	movement
19	Other equipment	Rubber suction hose, suction head, handrail, anchors, shelter, life jacket, etc.
20	Remark	1. Any data could be adjusted according to customers’ specific requirements. 2. Customized dredger acceptable according to requirements. 3. Engine power choose decided by dredger performance. 4. The work site situation will affect actual discharge distance, sand capacity, etc. 5. Above dredger size is not changeless, it could be adjusted according to specific circumstance.
