| Quantity: | |
|---|---|
The 14/12 Sand Dredge Pump is an ultra-heavy-duty centrifugal slurry pump engineered for large-scale sand dredging, mining, and high-capacity slurry transport. The designation "14/12" refers to its 14-inch (355mm) suction inlet and 12-inch (300mm) discharge outlet, making it ideal for industrial, marine, and mega-infrastructure projects requiring massive material handling.
Designed for extreme abrasion resistance, this pump features high-chrome alloy (Cr30), rubber lining, or ceramic composites to withstand continuous operation with highly abrasive slurries. Its optimized hydraulic design ensures maximum efficiency, low maintenance, and long service life even in the harshest environments.
✅ Ultra-Durable Construction
Cr30 high-chrome alloy (30% chromium) or ceramic-lined for extreme wear resistance
Reinforced double-wall casing for added structural integrity
Replaceable wear plates, impeller, and shaft sleeve for easy maintenance
✅ High-Performance Design
Handles particles up to 120mm (4.7 inches)
Flow capacity: 1,500–4,000 m³/h (up to 17,600 GPM)
Max head: 70m (230 ft) with optimized impeller design
Efficiency up to 80% for reduced energy costs
✅ Heavy-Duty Components
Extra-large bearings with oil lubrication for continuous operation
Multiple sealing options (mechanical seal, expeller, or gland packing)
Robust shaft design to prevent deflection under heavy loads
✅ Customizable Configurations
Horizontal or vertical mounting
Diesel, electric, or hydraulic drive options (up to 800HP/600kW)
Explosion-proof, submersible, or dry-installation models
| Parameter | Specification |
|---|---|
| Inlet/Outlet Size | 14" / 12" (355mm / 300mm) |
| Flow Rate | 1,500–4,000 m³/h |
| Max Head | 70m (230 ft) |
| Max Particle Size | 100–120mm |
| Operating Speed | 350–850 RPM |
| Power Requirement | 200–800 kW (270–1,070 HP) |
| Efficiency | Up to 80% |
| Material Options | Cr30, Rubber-Lined, Ceramic, Stainless Steel |
Marine & Dredging
Deep-sea sand mining and offshore dredging
Harbor deepening & channel maintenance
Beach nourishment & land reclamation
Mining & Heavy Industry
Large-scale sand & gravel extraction
Mineral sands & iron ore processing
Tailings transport in mega-mining operations
Major Construction & Infrastructure
Tunnel boring spoil removal
Dam construction & sediment management
Coastal protection & flood control projects
Specialized Uses
Sand bypass systems for ports
Environmental remediation dredging
High-density slurry pipelines
✔ Unmatched Durability – 3–5x longer lifespan than standard pumps due to premium materials.
✔ Massive Capacity – Handles high-density slurries with minimal wear.
✔ Low Maintenance – Modular design allows quick replacement of wear parts.
✔ Energy Efficient – Optimized impeller & volute reduce power consumption.
✔ Global Support – Available from leading manufacturers with worldwide service.
